We provide high quality Rockstar 400 Sheets & Plates that is used in the industry for the fabrication of many light weight heavy duty products that exhibit increased impact and abrasion resistance. This is widely demanded as it has excellent load bearing capacity, longer service life, toughness, etc. Further, its excellent cold rolling/bending capabilities, makes it perfect to make a number of precision engineering products. This Rockstar 400 Sheets & Plates can be availed in different specifications according to your application specific needs.
Available dimensions :
Rockstar 400 is abailable in thicknesses of 4.0 103mm. Rockstar 400 Tuf is available in thicknesses of 4 65 mm . Both grades are abailable in widths up to 3350 mm and lengths up to 14630 mm.
Details
Tolerance :
More details are given in SSAB's brochure 41-General product information Strenx, Rockstar 400, Armox and Toolox-UK or
Thickness mm | Hardness HBW min max | Typical yield strength Mpa , not guaranteed |
04/01/32 | 470 530 | 1250 |
(32) - 103 | 450 - 540 | 1250 |
Brinell hardness, HBW, according to EN ISO 6506 1, on a miled surface 0.5 3 mm below surface. Atleast one test specimen per heat and 40 tons . The nominal material thickness will ot deviate more than 15mm from that of the test specimen.
The plale are through hardened to a minimum of 90% of the guaranteed minimum surface hardness
Details
Impact properties | Rockstar 400 | Rockstar 400 Tuf Transverse test, guaranteed | Longitudinal test, typical |
Impact energy (j) for transverse tests Charpy V 10 * 10 mm test specimen | - | 27 J/0C | 37 J/40C |
For thicknesses between 6 11.9mm subsize Charpy V-Specimens are used. The specified minimum value is then proportional to the cross-sectional area of the test specimen. Compared to a full size specimen (10*10mm). Impact testing according to ISO EN 148 per heat and thickness group. Average of three tests. Single value minimum 70% of specified average. Impact test is performed from 6 mm .
Chemical Composition (Heat Analysis)
C | S | Mn | P | S | Cr | Ni | Mo | B |
0.3 | 0.7 | 1.6 | 0.02 | 0.01 | 1.5 | 1.5 | 0.6 | 0.01 |
Maximum Carbon equivalent CET (CEV)
Thickness mm | -(5) | 5-(10) | 10-(20) | 20-(40) | 40-103 |
CET (CEV) | 0.34 (0.49) | 0.36 (0.52) | 0.43 (0.64) | 0.45 (0.66) | 0.47 (0.75) |
